Rated impulse voltage

UL

IEC

Rated voltage

300V

250V

Rated current

8A

7A

Wire range

28-16AWG

0.5-1.5mm2

Rated impulse voltage

2.5KV

Withstanding voltage

Mechanical

Torque

0.2Nm(1.7Lb-In.)

Ambient temperature

-40°C~+105°C

Strip length

7mm

Dimensions

Pitch

3.5mm(.138")   3.81mm(.150")

Poles

8P,12P,16P,24P,32P

Material

Housing

PA66,UL94V-0

Screws

M3,steel,Cr³⁺ Zn plated

Contact

Copper,Tin plated

Copper block

Brass,Ni plated

Pin header

Brass,Tin plated

Wire guard

Stainless steel
